POWER AMPLIFIER

Accessories

digital oscilloscope

EGSTON Powerscope

EGSTON Powerscope turns your COMPISO System Unit into an even more powerful tool by helping you visualize and record system data and measurements. Using a 1Gbit Ethernet connection, up to 64 channels in 16-bit channel resolution at sampling rates of up to 250kHz can be displayed. EGSTON Powerscope is delivered preinstalled on a PC.

digital oscilloscope

Digital and analog channels

64 analog or digital channels with 16bit resolution

Sampling frequency

Data can be sampled with a frequency up to 1MHz

Real-time

Visualize system data and measurements in real-time

Data recording

record data for post-processing and analysis with an accuracy of 10 ns

CSU model for Hardware-in-the-Loop systems

COMPISO System Unit Simulation Model

Simulation model of the COMPISO System Unit for the use in 3rd party HIL systems like PLECS® or MATLAB®. Simulate your use case before turning the power on.

simulation models

Save time

accelerate development of your test scenarios significantly

Optimize processes

simplify debugging of your models

Easy implementation

available for PLECS® or MATLAB®

Fail-proof emulations

simulate your use case before turning the power on

Galvanically isolated analog and digital inputs and outputs

CABINET I/O Box

The CABINET I/O Box is an extension to the COMPISO System Unit. Connected through an optical fiber interface and fully galvanically isolated, it exchanges analog and digital data streams in real time, providing measured values as low-voltage outputs. Low-voltage inputs are available for set points. The digital inputs and outputs can also be used as internal or external event triggers.

galvanically isolated
low-voltage signals

Galvanically isolated

Connected through optical fibers

Potential-free

Potential-free low-voltage signals

Flexible

analog and digital inputs and outputs

Digital triggers

use digital inputs and outputs as internal or external event triggers

Solutions

Accessories

Made in Austria

Research & Development

EGSTON Power Electronics aims to develop products that consistently meet the highest expectations for quality, reliability and function. Our products are mounted in racks, yet we are not afraid to think outside the box, and we keep doing that throughout all phases of every single project to achieve total customer satisfaction. To this same end, we also maintain productive collaborations with internationally reputed research and education facilities.

Virginia Polytechnic Institute and State University
Blacksburg, USA
testing with CSU200 1GAMP6

Logo Virginia Polytechnic Institute and State University
Engineer with measuring instrument in front of the COMPISO CSU200

On-Site Service

Field Application and Training

Take advantage of our comprehensive after-sales service. Our on-site service team will be at hand for smooth installation and commissioning, complete with detailed hands-on training for your staff.
